Tungsten Carbide CNC Ball Nose Router Bits General Processing
Contact Person : KING
Phone Number : 86-18115005888
WhatsApp : +8618115005888
| Minimum Order Quantity : | 1PC | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | 1PC/ PVC Packing, 10pcs PVC Packing/Pack... | Delivery Time : | 1-35days |
| Payment Terms : | T/T, L/C,Paypal... | Supply Ability : | 10000pcs/week |
| Place of Origin: | MADE IN CHINA | Brand Name: | KTC |
|---|---|---|---|
| Certification: | CCC | Model Number: | HG680 |
|
Detail Information |
|||
| Product Name: | Ball Nose End Mill High Hard Material Processing Long Service Life | Precision: | High Precision |
|---|---|---|---|
| Flexural Strength: | 4600mpa | A.O.L: | 50mm-150mm |
| Grain Size: | 0.2 μm | Material: | Carbide,Tungsten Cobalt Alloy,Carbide/Tungsten |
| Suitable For: | Cast Iron,Carbon Steel,Copper,Stainless Steel,Cooper.Cast Iron.Carbon Steel.Mould Steel | Application: | CNC Process,CNC Milling Machining,Carbon Steel |
| Transport: | Air,Air/Courier/Maritime,TNT/UPS/DHL/Fedex/EMS,Express,Se | ||
| High Light: | cnc ball nose bit,hard milling end mills |
||
Product Description
Four Flutes Ball Nose End Mill High Hard Material Processing Long Service Life
Features
Specifications
| Raw Material | K44 |
| WC | 88% |
| Co | 12% |
| TRS | >4600N/mm2 |
| Hardness | >94HRA |
| A.O.L | 50mm-150mm |
| Grain size | 0.2μm |
| Upto | <HRC65 |
| Flutes No | 4F |
| Coating | Balzers |
| Suitable for | Steel,stainless steel,nickel alloy,Titanuim alloy,cast iron,plastic and other materials |
Standard Sizes
| Size | Flute Length of End Mills(mm) | |
| Flat end | Ball Nose | |
| D1*D4*50 | 3 | 2 |
| D1.5*D4*50 | 4 | 3 |
| D2*D4*50 | 5 | 4 |
| D2.5*D4*50 | 6 | 5 |
| D3*D4*50 | 8 | 6 |
| D3*D3*50 | 8 | 6 |
| D3.5*D4*50 | 9 | 7 |
| D4*D4*50 | 10 | 8 |
| D1*D6*50 | 3 | 2 |
| D1.5*D6*50 | 4 | 3 |
| D2*D6*50 | 5 | 4 |
| D2.5*D6*50 | 6 | 5 |
| D3*D6*50 | 8 | 6 |
| D3.5*D6*50 | 9 | 7 |
| D4*D6*50 | 10 | 8 |
| D6*D6*50 | 13 | 10 |
| D6*D6*50 | 15 | 12 |
| D7*D8*60 | 17 | 14 |
| D8*D8*60 | 20 | 16 |
| D10*75 | 25 | 20 |
| D12*75 | 30 | 24 |
| D14*100 | 45 | 28 |
| D16*100 | 45 | 32 |
| D18*100 | 45 | 36 |
| D20*100 | 45 | 40 |
| Flute Length of Extended End Mills(mm) | ||
| D3*D4*75 | 12 | 6 |
| D4*D4*75 | 16 | 8 |
| D5*D6*75 | 18 | 10 |
| D6*D6*75 | 25 | 12 |
| D8*75 | 30 | 16 |
| D3*D4*100 | 15 | 6 |
| D4*D4*100 | 20 | 8 |
| D5*D6*100 | 30 | 10 |
| D6*D6*100 | 30 | 12 |
| D8*D8*100 | 35 | 16 |
| D10*100 | 40 | 20 |
| D12*100 | 45 | 24 |
| D6*D6*150 | 40 | 12 |
| D8*D8*150 | 50 | 16 |
| D10*150 | 55 | 20 |
| D12*150 | 55 | 24 |
| D14*150 | 60 | 28 |
| D16*150 | 70 | 32 |
| D18*150 | 70 | 70 |
| D20*150 | 70 | 70 |
