Product Description
Black or Copper Center Cutting End Mill / 2 Flutes Milling End Mill Cutter
Tungsten Carbide Center Cutting End Mill Cutting Tools for Lathe Machine
1. Our advantages:
1. Solid carbide lasting long life in hardened steels, Grain size carbide, high toughness, high -wearing feature.
2. Reduce the rudding coefficient & save the processing time, Specializing in high speed cutting of CNC milling machine.
3. Wide range of application: Suitable for copper, castiron, carbon steel, stainlees steel, Non-ferrous material and Heat-treated steel processing.
4. The shank and helix angle can be customized according to customers' requirements.
Specifications:
D600 centering chamfer cutter series adopt domestic high-quality fine grain tungsten steel material, flexural strength: 4100mpa, grain size: 0.8μm. There are two categories for aluminum and steel respectively. The centering chamfer cutter for steel is coated by imported coating equipment (black / Bronze), especially suitable for aluminum, copper, ordinary medium and low carbon steel, alloy steel and other materials processing. With high precision quality control, and full inspection, all D600 series end mills are delivered with 100% qualification rate.
| Raw Material |
YL10.2 /K30 |
| WC |
90% |
| Co |
10% |
| TRS |
>4100N/mm2 |
| Hardness |
>92HRA |
| A.O.L |
50mm-100mm |
| Grain size |
0.8 μm |
| Upto |
HRC55 |
| Flutes No |
2F |
| Coating |
AlTiN or TiSiN |
| Suitable for |
Steel,stainless steel,nickel alloy,Titanium alloy,cast iron,plastic and other materials |
Coating:
| Item |
AlTiN |
TiSiN |
| Hardness(HV): |
3200 |
3600 |
| Thickness(μm): |
2.5-3 |
3 |
| Oxidation Temp(°): |
900 |
1000 |
| frictional Coefficient: |
0.3 |
0.45 |
| Color: |
Black |
Copper |
Standard Sizes
| Size |
Flute Length(mm) |
the Degrees of Angle |
| D4*50 |
8 |
60° 90° 120° |
| D4*100 |
8 |
60° 90° 120° |
| D6*50 |
12 |
60° 90° 120° |
| D6*100 |
12 |
60° 90° 120° |
| D8*60 |
16 |
60° 90° 120° |
| D8*100 |
16 |
60° 90° 120° |
| D10*75 |
20 |
60° 90° 120° |
| D10*100 |
20 |
60° 90° 120° |
| D12*75 |
24 |
60° 90° 120° |
| D12*100 |
24 |
60° 90° 120° |
| D16*100 |
32 |
60° 90° 120° |
| D20*100 |
40 |
60° 90° 120° |
Quality has never been more important than today. We continually invest in the latest technology and equipment in keeping with our pledge for quality excellence.
Only the best micro grain carbide available is used in building our tools. We offer a full line of tools, as well as custom manufactured tools in Solid Carbide/HSS Cobalt 8%, End Mills,Reamers, Step Drills and Form Tools are just a few of the types of tools that we will custom manufacture and coat to your specifications. We work together with you to make the exact cutting tool you are looking for.
Product Description:
1, Chemical Composition: 10%Co-Wc
2, Raw Material:Super Micro grain with Diameter less than 0.2UM
3, International Industrial Standard: K10, K05-K15, K20-K30, K20-K40
4, Technology and Processing Equipment:
Processing Equipment
1) grinding machine imported from Germany.
2)ANCA grinding machine imported from Australia.
Technology
incorporate latest molding, coating, edge preparation,and other manufacturing technology. Provide superior performance.
Coatings provide high-speed capability and are engineered from finishing to heavy roughing,The post-coat treatment reduces coating stresses, improves coating adhesion, minimises microchipping and edge build-up, and improves workpiece finish.Coated surface enable to get Longer tools life:
Application areas: Machining of cast iron, nonferrous alloy, chill cast iron, hard steel, stainless steel, plastic materials, fiberglass, carbon fiber and other non-metallic.
Served industries: Aerospace,Transportation,Medical Equipment,Military Manufacturing,Mold Development,etc.
After service:
1. If you are not satisfied with your purchase, you can exchange the item. The buyer is responsible for all further shipping costs.
2. The buyer must contact us within 3 days of delivery if they wish to exchange defective or incorrectly shipped items.
3. Exchange Steps:All items must be returned in their original condition, in order to quality for an exchange.
4. Please kindly note that: We do not cover any items for damage after use or as the result of water damage.
