Tungsten Carbide Solid Milling Cutter 4 Flutes Nano Coated High Precision

Contact Now

Tungsten Carbide Solid Milling Cutter 4 Flutes Nano Coated High Precision

Minimum Order Quantity :	10 pcs	Price :	Negotiation
Packaging Details :	1PC/ PVC Packing, 10pcs PVC Packing/Pack...	Delivery Time :	1-35days
Payment Terms :	T/T, L/C,Paypal...	Supply Ability :	10000pcs/week

Place of Origin:	MADE IN CHINA	Brand Name:	KTC
Certification:	CCC	Model Number:	E650

Detail Information
Product Name:	Tungsten Carbide Solid Milling Cutter 4 Flutes Nano Coated High Precision	Flutes No:	4 Flutes
Grain Size:	0.2 μm	A.O.L:	50-150mm
Flexural Strength:	4500mpa	Coating:	NACo/AlTiN
Co:	12%	Suitable For:	Steel,stainless Steel,nickel Alloy,Titanuim Alloy,cast Iron,plastic And Other Materials
Highlight:	hard milling end mills , solid carbide end mill

Product Description

Tungsten Carbide Solid Milling Cutter 4 Flutes Nano Coated High Precision

End mills come in a variety of shapes. The most common are flat end mills and ball end mills. Flat end mills will cut flat areas with no scallops. However, they leave a terrace-like scallop on non-flat surfaces. Ball end mills will leave smaller scallops for the same stepover value on sloped surfaces, but they will also leave scallops on flat areas.

Models can be tooled with a combination of flat and ball end mills. If only one tool will be used for all surfaces a ball end geometry will give a more consistent overall feel and smooth result.

Flat end mills can be Center Cutting and Non Center Cutting: Center cutting square endmills are essential for plunge milling. Non-center cutting mills are used only for side milling.

Great Performance

Made of high quality carbide, it is high-wearable and has a long life. You can decrease the times of changing cutters, save production time.

Carbide end mills provide better rigidity and can be run faster than other material end mills.

Straight shank handle, rounded chamfer design for easy installation and improved work efficiency.

Widely Application

4 flutes end mill can be used on many fields, such as metal processing, CNC machining and engineering using, ideal for peripheral and finish milling.

Large chip flute design for smoother chip removal, making the workpiece smoother and brighter.

Specifications

Raw Material	AF308/510
WC	88%
Co	12%
TRS	>4500N/mm2
Hardness	>94HRA
A.O.L	50-150mm
Grain size	0.2μm
Upto	<HRC65
Flutes No	4F
Coating	nACo/AlTiN
Suitable for	Steel,stainless steel,nickel alloy,Titanuim alloy,cast iron,plastic and other materials

Coating:

Item	AlTiN	nACo
Hardness(HV)	3200	42(GPA)
Thickness(μm)	2.5-3	3
Oxidation temp(°)	900	1200
Friction coeffient	0.3	0.4
Color	Black	Blue

Standard Sizes

Size	Flute Length of End Mills(mm)
Size	Flat end	Ball Nose	Round nose
D1D450	3	2	3
D1.5D450	4	3	4
D2D450	5	4	5
D2.5D450	6	5	6
D3D450	8	6	8
D3D350	8	6	8
D3.5D450	9	7	9
D4D450	10	8	10
D1D650	3	2	3
D1.5D650	4	3	4
D2D650	5	4	5
D2.5D650	6	5	6
D3D650	8	6	8
D3.5D650	9	7	9
D4D650	10	8	10
D6D650	13	10	13
D6D650	15	12	15
D7D860	17	14	17
D8D860	20	16	20
D10*75	25	20	25
D12*75	30	24	30
D14*100	45	28	35
D16*100	45	32	40
D18*100	45	36	40
D20*100	45	40	40
Flute Length of Extended End Mills(mm)
D3D475	12	6	12
D4D475	16	8	14
D5D675	18	10	15
D6D675	24	12	20
D8*75	25	16	25
D3D4100	12	6	15
D4D4100	20	8	15
D5D6100	20	10	20
D6D6100	30	12	25
D8D8100	35	16	30
D10*100	40	20	30
D12*100	45	24	35
D6D6150	45	12	40
D8D8150	50	16	45
D10*150	55	20	50
D12*150	55	24	55
D14*150	60	28	60
D16*150	70	32	65
D18*150	70	36	70
D20*150	70	40	70

Packing & Delivery

Tungsten Carbide Solid Milling Cutter 4 Flutes Nano Coated High Precision 0

Packing of Custom tungsten carbide end mills

1> One piece in a platic pipe, 10 pieces per group.

2> Use the air bubble paper to encase the plastic pipe.

3> Put the goods encased with air bubble paper in the carton.

4> Other packing will be accept according to your needs.
